Cisco Multiband Indoor 4G Volcano Antenna (ANT-4G-CM-IN-TNC)
7. Place the self-adhesive screw covers (3) over the screw holes on the antenna.
8. Attach the cable to the antenna connector.
9. Attach the router-end of the cable to your router.
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly
What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
1 Mounting anchors for hard ceiling (3) 2 Mounting nut
3 Curved spring washer 4 Flat washer (wide series)
5 #6 1-1/4” mounting screws (3) 6 Self-adhesive screw covers (3)
7 50.8 mm 8 86.0 +/- 1.0 mm
9 75.0 +/- 1.0 10 Ceiling, hard wall material
300686
1
2
10
7
8
9
3
4
5
6
