Cisco Multiband Indoor 4G Volcano Antenna (ANT-4G-CM-IN-TNC)
Figure 1 4G Volcano Antenna
RF Specifications
Mechanical Specifications
Specification Description
Frequency range 698 to 960 MHz
1575 MHz
1710 to 2700 MHz
Peak gain  1 dBi (698 to 960 MHz)
 2 dBi (1575 MHz)
 3 dBi (1710 to 2700 MHz)
VSWR  2.0:1 (698 to 960 MHz)
 2.5:1 (1575 MHz)
 2.0:1 (1710 to 2700 MHz)
H-plane (3 dB beamwidth) Omnidirectional
Efficiency Antennas were designed and tested to high RF efficiency in all
supported cellular bands. Detailed technical specifications
can be obtained through your Cisco authorized partner or
Cisco account representative.
Polarization Linear, vertical
281565
