Cisco Aironet 2.4 GHz 13-dBi Directional Antenna (AIR-ANT2413P2M-N)
Technical Specifications
System Requirements
This antenna is designed for use with Cisco Aironet access points and bridges but can be used with any 2.4-GHz Cisco Aironet
radio device that uses an N-male connector.
Antenna type 2-Element Patch
Array
Operating frequency range 2400 to 2500 MHz
Nominal input impedance 50 Ohms
Peak gain 13 dBi
Polarization Linear, Dual
Elevation plane 3-dB
beamwidth
30°
Azimuth plane 3-dB
beamwidth
30°
Sidelobe level < –20 dBc
Front-to-back ratio > 25 dB
Cable length and type 30 in. (76.2 cm)
outdoor rated Coax
Connector type N Male
Length 7.8 in. (19.8 cm)
Width 7.8 in. (19.8 cm)
Height 1.2 in. (3 cm)
Weight 21.6 oz. (0.61 kg)
Operating temperature
range
–40°F to 131°F
(–40°C to 55°C)
Elevation and Azimuth Plane Patterns
