Antenna Selection Table
EOS Antennas
Table 2 EOS Antennas
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
Outdoor Panel Antenna for WiMAX 1.8, 2.5, and
3.8 GHz.
Outdoor Panel Antenna for WiMAX 1.8, 2.5, and
3.8 GHz
N female (x2) WiMAX 1.8, 2.5, 3.8
GHz.
16 +/- 1 dBi
CGR 1000
Connected Grid Modules
ANT-WM-INT-OUT-M
(Similar to ANT-MP2-I-O-SS-M, except covering
3.3-3.6 GHz)
MCX jack 3.3-3.8 GHz
N/A
WiMax CGM module only.
Cisco Multiband Panel Outdoor 3G Antenna
(ANT-3G-PNL-OUT-N).
Multiband Panel Outdoor 3G antenna designed to
cover cellular 3G bands.
Type N female 3G
10 dBi 806-960 MHz
11 dBi 1710-2170
MHz
CGM-3G modules only
Cisco Multi-purpose Integrated Antenna
(ANT-MP-INT-OUT-M).
Multi-purpose integrated monopole antenna,
chassis-mounted, omnidirectional, includes
non-integrated coaxial cable. No cable (option
class).
MCX jack 3G
2.8 dBi 806-960
MHz
3.5 dBi 1710-2170
MHz
4 dBi 2300-2700
MHz
CGM-3G only in CGR1240
chassis.
This antenna is not
mechanically compatible with
CGR1120 chassis
Cisco Outdoor Omni Antenna for 900 MHz WPAN
(ANT-WPAN-OM-OUT-N).
Outdoor Omnidirectional Antenna for the 900 MHz
WPAN module.
Note: Antenna will eventually be obsoleted in favor
of the dual band 5 dBi, ANT-LPWA-DB-O-N-5
Type N female WPAN 902-928 MHz
only
4 dBi
IR509, IR510, and IR529 as
well as WPAN
CGM-WPAN-FSK-NA and
CGM-WPAN-OFDM-FCC
modules in CGR1240 and
CGR1120
