Cisco 4G/3G Omnidirectional Dipole Antenna (4G-LTE-ANTM-D)
Specifications
Figure 2 Elevation Cut (AMPS) Phi 0 Degree Plane for Cisco 4G-LTE-ANTM-D
Table 1 Specifications for Cisco 4G-LTE-ANTM-D Antenna
Specification Description
Maximum input power 3W
Connector TNC male
VSWR 2.5:1 or less
Characteristic impedance 50 ohm
Antenna base and radome color Cisco Raven Black
Antenna dimensions 9 (L) x 1.2 (W) x 7/16 in (D)
(229 x 30.5 x 11 mm)
Operating temperature –22° to 158°F (–30° to 70°C)
Operating frequency ranges  698–806 MHz
 824–894 MHz
 925–960 MHz
 1710–1885 MHz
 1920–1980 MHz
 2110–2170 MHz
 2500–2690 MHz
Efficiency Antennas were designed and tested to high RF
efficiency in all supported cellular bands. Detailed
technical specifications can be obtained through
your Cisco authorized partner or Cisco account
representative.
Maximum Peak Gain 2 dBi

Cisco AIR-ANT2544V4M-R Specifications
