Cisco Indoor Swivel-mount Dipole Antenna (ANT-4G-DP-IN-TNC)
RF Specifications
Mechanical Specifications
Radiation Patterns
Figure 2 Swivel-mount Dipole Antenna Radiation Patterns
Specification Description
Frequency ranges 698 to 806 MHz
824 to 894 MHz
880 to 960 MHz
1710 to 1880 MHz
1850 to 1990 MHz
1920 to 2170 MHz
2100 to 2500 MHz
2500 to 2690 MHz
Peak gain (dBi) 0.5 dBi (698 to 960 MHz)
2.2 dBi (1710 to 2700 MHz)
Efficiency Antennas were designed and tested to high RF efficiency in all
supported cellular bands. Detailed technical specifications can be
obtained through your Cisco authorized partner or Cisco account
representative.
VSWR < 2.5:1
Nominal impedance 50 ohms
Polarization Linear
Specification Description
Type Dipole
Size (L x W x D) 229 mm x 30.5 mm x 15 mm
Mount style Direct mount
Environment Indoor
RF Connector TNC (m)
Antenna weight 49 g
Operational temperature -31 to 158 degrees F (-35 to +70 degrees C)
Maximum input power 3 watts
Material substance compliance RoHS compliant
