Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R)
Obtain Documentation and Submit a Service Request
Figure 4 Locations of the Screw Holes on the Articulating Mount Flange
Installing the Antenna
You can install the antenna on a wall or ceiling (must be a flat surface), or on a pole with a minimum diameter of 2 inches
(5.08 cm) and a maximum diameter of 5 inches (12.7 cm). The antenna and one mounting flange are connected together when
shipped.
To install the antenna:
1. Decide on a mounting location. See the Deciding on a Mounting Location.
2. Ensure that you have the requisite tools and fasteners ready. See the Tools and Equipment Required.
3. Proceed with mounting the antenna. When mounting the antenna, assemble the bracket hardware, connect the antenna
and bracket to the mounting surface, and adjust the antenna orientation.
The mounting options available are:
1. Mounting on a Wall or Ceiling.
2. Mounting on a Pole or Mast.
3. Flush Mounting on a Wall Without Mount Brackets.
4. (Optional) Paint the antenna. See Painting the Antenna.
353897
4X
4.50
62.0
83.1
