482

Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R)

Figure 3 Locations of Screw Holes and Pressure Vent at the Back of the Antenna

353894

62.0

83.1

PRESSURE RELEASE

VENT

4X M4x0.7 THREADED

INSERT
