Cisco 5-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-5-4G2WL2G1-O)

4900 MHz WLAN Antenna Radiation Patterns

Figure 10 4900 MHz WLAN Antenna Radiation Patterns

5150 MHz WLAN Antenna Radiation Patterns

Figure 11 5150 MHz WLAN Antenna Radiation Patterns

Line Color Description

Blue (

—)Port 1

Red (—)Port 2

Line Color Description

Blue (

—)Port 1

Red (

—)Port 2
