Cisco Integrated 4G Low-profile Outdoor Saucer Antenna (ANT-4G-SR-OUT-TNC)
Radiation Patterns
The following graphics show the radiation patterns of the saucer antenna.
Specification Description
H-plane 3 dB beamwidth Omnidirectional
Polarization Linear, vertical
Nominal impedance 50 ohm
Power 3 watts
Cable 15 foot LMR 195
RF connector TNC(m)
Mount Style Stud mount, 5/8-18-NF mounting stud, mount on the roof or
suitable flat surface
Radome PC/ABS, UV stable, black
Material substance compliance RoHS compliant
Operational temperature -22 to 158 degrees F (-40 to 70 degrees C)
Storage temperature -40 to 185 degrees F (-40 to 85 degrees C)
Environment Outdoor, IP67, IK-08
Dimensions (ht x OD) 3.4 inches x 7.9 inches (87 mm x 200 mm)
Weight 0.75kg
