Antenna Selection Table
Cisco Outdoor Omnidirectional Antenna
for 2G/3G/4G Cellular
(ANT-4G-OMNI-OUT-N).
Outdoor Omnidirectional Antenna for
2G/3G/4G Cellular antenna is designed to
cover domestic
LTE700/Cellular/PCS/AWS/MDS, WiMAX
2300/2500, and
GSM900/GSM1800/UMTS/LTE2600
bands.
N-Type female 1.5 dBi 698-960 MHz
2 dBi 1448-1511 MHz
3.5 dBi 1710-2700 MHz
IR807, IR809, and IR829
IR1101 with P-LTE cellular
module
C819HG-LTE and
C819HG-4G
CGM-3G and CGM-4G
modules with CGR1120 and
CGR1240.
In most cases adapters or
cables are required.
Cisco Multiband Panel Outdoor 4G MIMO
Antenna (ANT-4G-PNL-OUT-N).
Multiband Panel Outdoor 4G MIMO
dual-port antenna designed to cover
cellular 4G bands.
Dual type N female
direct connector
698-960 MHz 8.0-10.0 dBi
1710-2170 MHz 6.0-8.5
dBi
2200-2400 MHz 6.5-9.5
dBi
2500-2700 MHz 8.5-9.5
dBi
Antenna is not designed to
operate in 1448-1511 MHz
Japan band. Does not have
high gain.
IR807, IR809, and IR829
IR1101 with P-LTE cellular
module
C819HG-LTE and
C819HG-4G
CGM-3G and CGM-4G
modules with CGR1120 and
CGR1240.
In most cases adapters or
cables are required.
Cisco Multiband Indoor 4G Volcano
Antenna (ANT-4G-CM-IN-TNC).
Multiband Indoor 4G Ceiling-mount
Volcano Antenna.
1 x TNC (m) 1 dBi 698-960 MHz
3 dBi 1710-2700 MHz
IR807, IR809, and IR829
C819HG-LTE and
C819HG-4G
CGM-3G and CGM-4G
modules with CGR1120 and
CGR1240.
For CGM / CGR use case
adapters are required
ANT-MP2-I-OUT-M and
ANT-MP2-I-O-SS-M Antenna and Cable
Kits.
For 4G cellular use you need the
ANT-MP2-I-O-SS-M antenna kit. The kit
has qty 2 antennas and cables needed for
Main and Aux cellular ports.
ANT-MP2-I-OUT-M is for 915 MHz
WPAN, and only has a single antenna and
cable in the kit.
Designed for direct mounting on the
CGR1240 and has an MCX connector.
MCX jack 0.9 dBi typical, 2.8 dBi max
698-960 MHz
3.0 dBi typical, 4.3 dBi max
1710-2700 MHz
4.0 dBi typical, 5.0 dBi max
2300-2700 MHz
Note: Degraded
performance in Japan
1448-1511 MHz band.
ANT-MP2-I-O-SS-M kit is
compatible with CGM-3G
and CGM-4G in CGR1240
chassis.
The antennas are not
mechanically compatible with
the CGR1120 chassis.
Part Number / Description RF Connectors Antenna Frequency Band
Support and Gain
Industrial Products Where
Supported
