Antenna Selection Table
Cisco GPS Antenna (ANT-GPS-OUT-TNC).
Active GPS antenna, integrated 15' LMR-100
cable with RA-TNC(male).
The ANT-GPS-OUT-TNC integrated GPS RF front
end is designed to reject collocated RF
interference.
Right-angle TNC
male
Active GPS antenna,
4.0 dBi min at
Zenith, 1575.42
MHz, plus 25dB
amplifier gain
CGR1120 router use case
requires ANT-ADPTR-Q-TNC
adapter. Router has a QMA(f)
GPS connector
LoRaWAN gateways,
IXM-LPWA-800-16-K9IXM-L
PWA-900-16-K9 directly
attached. No adapter needed,
as IXM products have TNC(f)
GPS connector.
IR510 use case requires
LTE-ADPT-SM-TF adapter.
IR510 has SMA(f) GPS
connector
IR1101 with P-LTE cellular
module
C819HG-LTE and C819HG-4G
IR807, IR809, and IR829
All of these use cases require a
LTE-ADPT-SM-TF adapter as
these routers have a SMA(f)
GPS connector.
Instead of a standalone
ANT-GPS-OUT-TNC antenna
please consider using a
multi-element antenna that
combines LTE and GPS
antennas in a single antenna
product such as:
ANT-5-4G2WL2G1-O or
ANT-3-4G2G1-O
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
