Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R)
Obtain Documentation and Submit a Service Request
Figure 6 Close-Up View of the Azimuth and Elevation-Adjustment Pivots
353898
ANGULAR DETENTS
EVERY 5
ANGULAR MARKINGS
EVERY 5
, LABELS AT
30 & 60
