Cisco Aironet 2.4-GHz/5-GHz 8-dBi Directional Antenna (AIR-ANT2588P3M-N)
Technical Specifications
Antenna type 3-element dual-polarized patch
Operating frequency range 2400–2500 MHz
5150–5900 MHz
Nominal input impedance 50 Ohms
VSWR 2:1 or less
Peak gain 8 dBi (both bands)
Polarization Linear, Dual
Elevation Plane 3-dB Beamwidth 30°
Azimuth Plane 3-dB Beamwidth 120°
Sidelobe level < –20 dBc
Front-to-back ratio > 10 dB
Length 12 in. (30.48 cm)
Width 7 in. (17.78 cm)
Height 1.1 in. (2.79 cm)
Weight 16 oz. (0.45 kg)
Connector type N-Female Bulkhead (x3)
Operating temperature range -40–131° F
(-40–55° C)
Environment rating IP67
