243
Cisco Aironet 5-GHz 13-dBi Directional Antenna (AIR-ANT5114P2M-N)
Figure 1 Attaching Antenna Mount Bracket
3. Attach elevation adjustable bracket as shown and loosely secure hardware. The carriage bolt square holes must be on the
inside.
1 Antenna mount bracket 3 1/4-in. spring lock washer
2 1/4-in. flat washer 4 1/4-in. 20 hex nut
334630
1
2
3
4
