Cisco RF Cables and Accessories
Table 6 N(m) to TNC(m) RF cable
Table 7 TNC(m) to TNC(f) RF cable
Antenna Cable Type Description RF Loss
CAB-L400-20-TNC-N TNC(m)-RA to N(m)-STR
LMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
0.8dB @ 0.7 GHz
1.0dB @ 1.0 GHz
1.3dB @ 1.7 GHz
1.6dB @ 2.4 GHz
CAB-L400-50-TNC-N TNC(m)-RA to N(m)-STR
LMR-400, 50 foot RF cable
Type: outdoor DB (direct burial)
1.9dB @ 0.7 GHz
2.3dB @ 1.0 GHz
3.1dB @ 1.7 GHz
3.8dB @ 2.4 GHz
Antenna Cable Type Description RF Loss
4G-CAB-LMR400-10 TNC(m)-RA to TNC(f)-STR
LMR-400, 10 foot RF cable
Type: outdoor DB (direct burial)
0.4dB @ 0.7 GHz
0.5dB @ 1.0 GHz
0.7dB @ 1.7 GHz
0.8dB @ 2.4 GHz
4G-CAB-ULL-20 TNC(m)-RA to TNC(f)-STR
LMR-400, 20 foot RF cable
Type: Plenum
0.8dB @ 0.7 GHz
1.0dB @ 1.0 GHz
1.3dB @ 1.7 GHz
1.6dB @ 2.4 GHz
4G-CAB-LMR240-25 TNC(m)-RA to TNC(f)-STR
LMR-240, 25 foot RF cable
Type: Plenum
1.9dB @ 0.7 GHz
2.3dB @ 1.0 GHz
3.0dB @ 1.7 GHz
3.6dB @ 2.4 GHz
4G-CAB-LMR240-50 TNC(m)-RA to TNC(f)-STR
LMR-240, 50 foot RF cable
Type: Plenum
Note: The cable is not recommended for longer distance links due to high
loss of 50 foot LMR240 at most cellular frequencies. The customer may need
to do a site survey to validate whether the cable allows sufficient
signal-to-noise ratio to or from cell tower.
3.7dB @ 0.7 GHz
4.5dB @ 1.0 GHz
5.9dB @ 1.7 GHz
7.2dB @ 2.4 GHz
4G-CAB-ULL-50 TNC(m)-RA to TNC(f)-STR
LMR-400, 50 foot RF cable
Type: Plenum
1.9dB @ 0.7 GHz
2.3dB @ 1.0 GHz
3.1dB @ 1.7 GHz
3.8dB @ 2.4 GHz
4G-CAB-LMR240-75 TNC(m)-RA to TNC(f)-STR
LMR-240, 75 foot RF cable
Type: Plenum
Note: The cable is not recommended for high throughput or longer distance
links due to high loss of 75 foot LMR240 at most cellular frequencies. The
customer may need to do a site survey to validate whether the cable allows
sufficient signal-to-noise ratio to or from cell tower.
5.5dB @ 0.7 GHz
6.7dB @ 1.0 GHz
8.8dB @ 1.7 GHz
10.7dB @ 2.4 GHz
