Cisco 3G/4G LTE and LTEA Omnidirectional Dipole Antenna (LTE-ANTM-D)
Figure 3 698, 824, 960 MHz Cellular Antenna Radiation Pattern (dBi), Elevation, Phi = 0
-40
-35
-30
-25
-20
-15
-10
-5
0
5
0
30
60
90
120
150
180
210
240
270
300
330
Theta Angle (°)
ZX Plane
( niaG dBi)
Z
X
366532
698MHz 824MHz 960MHz
-5.08
1.35
140
-5.14
1.28
120
-5.22
1.42
95
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
698MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
824MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
960MHz
