Cisco 3G/4G LTE and LTEA Omnidirectional Dipole Antenna (LTE-ANTM-D)
Figure 5 1710, 2170, 2690 MHz Antenna Radiation Pattern (dBi), Azimuth
-40
-35
-30
-25
-20
-15
-10
-5
0
5
0
30
60
90
120
150
180
210
240
270
300
330
Phi Angle (°)
XY Plane
366534
X
Y
Gain (dBi)
1710MHz 2170MHz
2690MHz
-3.45
-0.89
230
-2.26
-0.77
295
-1.54
0.64
250
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
1710MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
2170MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
2690MHz
