Cisco AIR-ANT2544V4M-R Guide

517
Cisco 4G LTEA, 4G LTE, and 3G Omnidirectional Dipole Antenna (LTE-ANTM-SMA-D)
Figure 4 698, 824, 960 MHz Cellular Antenna Radiation Pattern (dBi), Elevation, Phi = 90
-40
-35
-30
-25
-20
-15
-10
-5
0
5
0
30
60
90
120
150
180
210
240
270
300
330
Theta Angle (°)
YZ Plane
366533
Gain (dBi)
Z
Y
698MHz 824MHz 960MHz
-5.14
1.45
125
-5.38
1.31
105
-6.08
1.51
95
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
698MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
824MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
960MHz
