Outdoor Panel Antenna for WiMAX 1.8, 2.5, and 3.8 GHz
This section lists the technical information for the Flat Panel Outdoor WiMAX Antenna.
The Flat Panel Outdoor WiMAX Antenna has Azimuth radiation patterns:
Specification Description
Type Directional panel
Frequency 2.3 to 2.7 GHz
Nominal gain 16 dBi, (2.3 to 2.4 GHz)
18 dBi (2.4 to 2.7 GHz)
Polarization Dual linear (vertical and horizontal) or slant +/- 45 degrees
Maximum input power 25 Watts
Antenna 14.5 x 14.5 x 1.75 in. (36.8 x 36.8 x 4.4 cm)
Weight 3.5 lbs (1.6 kg)
Connector Dual type N female
Mount style Wall or pipe mount
Environment Outdoor
Temperature range (operating) -40 to 185-degrees F (-40 to 85-degrees C)
Radiation pattern Directional
