Antenna type Low profile, ceiling-mount omnidirectional
Operating frequency range  698–806 MHz
 824–894 MHz
 925 –960 MHz
 1575 MHz
 1710–1885 MHz
 1920–1980 MHz
 2110–2170 MHz
 2500–2690 MHz
Nominal Impedance 50 Ohms
Voltage Standing Wave Ratio (VSWR)  2.0:1
 3.01:1 or less for GPS
Gain  700–960 MHz (1 and 1.5 dBi)
 1700–2200 MHz (1.7 and 3.2 dBi)
 2500–2700 MHz (3 and 4 dBi)
Radiation Pattern:
Vertical plane (-3 dB beam-width)
 700–960 MHz (80 and 95 degrees)
 1700 MHz (80 and 90 degrees)
 1800 MHz (75 and 95 degrees)
 1900 MHz (65 and 90 degrees)
 2100 MHz (50 and 65 degrees)
 2500–2700 MHz (50 and 65 degrees)
Azimuth plane ripple 3.5 dB over all frequencies
Efficiency 70-85% over all supported frequencies
Connector type TNC-Male
Polarization Linear (vertical)
Power withstanding 3 W
Weight 0.7 lb (0.34 kg)
Color White
Flammability UL94 V0
Environment Indoor
Mounting Nut, flat washer, curved spring washer, #6 x 1-1/4” mounting
screws and anchors to be used for mounting to a hard ceiling,
self adhesive screw covers.
Operating temperature –22° to 158°F (–30° to 70°C)
Storage temperature –40° to 185°F (–40° to 85°C)
