The scale profile should be configured in the administration configuration. If you previously configured
the L3 scale profile in the global configuration, the following limitations apply:
Note
•
If the scale profile is set only in the global configuration, the setting takes affect.
•
Scale profile settings in the administration configuration override scale profile settings in the global
configuration.
•
Cisco recommends that you configure all scale profile settings in the administration configuration
and remove the global configuration settings. For more information, refer to Removing the Scale
Profile from the Global Configuration, on page 9.
SUMMARY STEPS
1.
admin
2.
configure
3.
hw-module profile scale{default | l3 | l3xl}
4.
commit
5.
reload location all
6.
show running-config
7.
show hw-module profile
DETAILED STEPS
PurposeCommand or Action
Enters administration EXEC mode.admin
Example:
RP/0/RSP0/CPU0:router# admin
Step 1
Enters administration configuration mode.configure
Example:
RP/0/RSP0/CPU0:router(admin)# configure
Step 2
Specifies the scale profile for the router.hw-module profile scale{default | l3 | l3xl}
Step 3
Example:
RP/0/RSP0/CPU0:router(admin-config)#
hw-module profile
• default—efficient for deployments that require large Layer 2
MAC tables (up to 512,000 entries) and a relatively small number
of Layer 3 routes (less than 512,000).
scale l3xl
• l3—efficient for deployments that require more Layer 3 routes
(up to 1 million) and smaller Layer 2 MAC tables (less than
128,000 entries).
Sun Nov 14 10:04:27.109 PST
In order to activate this new memory
resource profile,
you must manually reboot the system.
• l3xl—efficient for deployments that require a very large number
of Layer 3 routes (up to 1.3 million) and minimal Layer 2
Cisco ASR 9000 Series Aggregation Services Router System Management Configuration Guide, Release 5.1.x
6
Configuring Profiles
Configuring the Scale Profile
