Cisco Extension Actions
The set ipv4 or set ipv6 nexthop actions are used to redirect an ipv4 or ipv6 packet to the specified nexthop
address, instead of using the destination address in the packet. This provides ABF (ACL Based Forwarding)
kind of functionality using OpenFlow. However, VRF support and nexthop tracking as supported by CLI
based ABF feature is not supported in this release.
The set fcid (Forward Class ID) action can be used to support PBTS (Policy Based Tunnel Selection)
functionality using OpenFlow.
Following table shows the list of actions added by Cisco to support some extra features on ASR9K.
OpenFlow Switch Types Supported on ASR9KCisco proprietary actions
Applied to L3 or L3 VRF interfaceApplied to L2 Bridge domain
L3_DSL3_V4L2_L3L2 onlyDescriptionOXM Flow match field
type for OpenFlow
basic class
YesYesNoNoSet ipv4
nexthop
address
Set Ipv4 Nexthop
YesNoNoNoSet ipv6
nexthop
address
Set Ipv6 Nexthop
YesYesNoNoSet forward
class ID
Set Forward Class ID
Set Field Actions
This table lists the set field actions supported by the Cisco ASR 9000 series router:
OpenFlow Switch Types Supported on ASR9KOpenFlow Matches
Applied to L3 or L3 VRF interfaceApplied to L2 Bridge domain
L3_DSL3_V4L2_L3L2 onlyDescriptionOXM Flow match field
type for OpenFlow
basic class
NoNoYesYesEthernet
destination
address
OFPXMT_OFB_ETH_DST
NoNoYesYesEthernet
source
address
OFPXMT_OFB_ETH_SRC
Cisco ASR 9000 Series Aggregation Services Router System Management Configuration Guide, Release 5.1.x
284
Implementing Open Flow Agent
Cisco Extension Actions
