OpenFlow Switch Types Supported on ASR9KOpenFlow Actions
Applied to L3 or L3 VRF interfaceApplied to L2 Bridge domain
L3_DSL3_V4L2_L3L2 onlyDescriptionOXM Flow action field
type for OpenFlow
basic class
NoNoYesYesOutput to
switch port.
OFPAT_OUTPUT
NoNoNoNoCopy TTL
"outwards"
OFPAT_COPY_TTL_OUT
NoNoNoNoCopy TTL
"inwards"
OFPAT_COPY_TTL_IN
NoNoNoNoMPLS TTLOFPAT_SET_MPLS_TTL
NoNoNoNoDecrement
MPLS TTL
OFPAT_DEC_MPLS_TTL
NoNoYesYesPush a new
VLAN tag
OFPAT_PUSH_VLAN
NoNoYesYesPop the outer
VLAN tag
OFPAT_POP_VLAN
NoNoNoNoPush a new
MPLS tag
OFPAT_PUSH_MPLS
NoNoNoNoPop the outer
MPLS tag
OFPAT_POP_MPLS
NoNoNoNoSet queue id
when
outputting to
a port
OFPAT_SET_QUEUE
NoNoNoNoApply groupOFPAT_GROUP
NoNoNoNoIP TTLOFPAT_SET_NW_TTL
NoNoNoNoDecrement IP
TTL
OFPAT_DEC_NW_TTL
YesYesYesYesSet a header
field using
OXM TLV
format
OFPAT_SET_FIELD
NoNoNoNoPush a new
PBB service
tag (I-TAG)
OFPAT_PUSH_PBB
NoNoNoNoPop the outer
PBB service
tag
OFPAT_POP_PBB
