DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Enters configuration mode for the specified clock interface.
clock-interface sync value location node
Example:
RP/0/RSP0/CPU0:router(config)# clock-interface
Step 2
sync 1
location 0/RSP0/CPU0
Configures the port parameters for the clock interface.port-parameters dti
Example:
RP/0/RSP0/CPU0:router(config-clock-if)#
port-parameters dti
Step 3
Enters frequency synchronization mode for the clock interface.frequency synchronization
Example:
RP/0/RSP0/CPU0:router(config-clock-if)#
frequency synchronization
Step 4
Configures selection input for the clock interface.selection input
Example:
RP/0/RSP0/CPU0:router(config-clk-freqsync)#
selection input
Step 5
Configures priority for the clock interface.
priority number
Example:
RP/0/RSP0/CPU0:router(config-clk-freqsync)#
priority 10
Step 6
Configures the wait-to-restore time for the clock interface.
wait-to-restore number
Example:
RP/0/RSP0/CPU0:router(config-clk-freqsync)#
wait-to-restore 0
Step 7
Disables SSM packets for the clock interface.ssm disable
Example:
RP/0/RSP0/CPU0:router(config-clk-freqsync)#
ssm disable
Step 8
Cisco ASR 9000 Series Aggregation Services Router System Management Configuration Guide, Release 5.1.x
244
Configuring PTP
Configuring the Clock Interface for a PTP Master
