Cisco CRS Configuration Guide

Verifies that graceful restart is enabled locally.
Example:
RP/0/RP0/CPU0:router# show rsvp graceful-restart
Graceful restart: enabled Number of global
neighbors: 1 Local MPLS router id: 10.51.51.51 Restart time: 60 seconds
Recovery time: 0 seconds Recovery timer: Not running Hello interval: 5000
milliseconds Maximum Hello miss-count: 3
Step 6
show rsvp graceful-restart [neighbors ip-address | detail]
Verifies that graceful restart is enabled on the neighbor(s). These examples show that neighbor 192.168.60.60 is not
responding to hello messages.
Example:
RP/0/RP0/CPU0:router# show rsvp graceful-restart neighbors 192.168.60.60
Neighbor App State Recovery Reason
Since LostCnt --------------- ----- ------ -------- ------------
-------------------- -------- 192.168.60.60 MPLS INIT DONE N/A 12/06/2003
19:01:49 0
RP/0/RP0/CPU0:router# show rsvp graceful-restart neighbors detail
Neighbor: 192.168.60.60 Source: 10.51.51.51
(MPLS) Hello instance for application MPLS Hello State: INIT (for 3d23h)
Number of times communications with neighbor lost: 0 Reason: N/A Recovery
State: DONE Number of Interface neighbors: 1 address: 10.64.64.65 Restart
time: 0 seconds Recovery time: 0 seconds Restart timer: Not running Recovery
timer: Not running Hello interval: 5000 milliseconds Maximum allowed missed
Hello messages: 3
Step 7
show rsvp interface
Verifies the available RSVP bandwidth.
Example:
RP/0/RP0/CPU0:router# show rsvp interface
Interface MaxBW MaxFlow Allocated MaxSub -----------
-------- -------- --------------- -------- Et0/0/0/0 0 0 0 ( 0%) 0 PO0/3/0/0
1000M 1000M 0 ( 0%) 0 PO0/3/0/1 1000M 1000M 0 ( 0%) 0 PO0/3/0/2 1000M 1000M
0 ( 0%) 0 PO0/3/0/3 1000M 1000M 1K ( 0%) 0
Step 8
show rsvp neighbor
Verifies the RSVP neighbors.
Example:
RP/0/RP0/CPU0:router# show rsvp neighbor detail
Global Neighbor: 40.40.40.40 Interface Neighbor: 1.1.1.1
Interface: POS0/0/0/0 Refresh Reduction: "Enabled" or "Disabled". Remote
epoch: 0xXXXXXXXX Out of order messages: 0 Retransmitted messages: 0
Interface Neighbor: 2.2.2.2 Interface: POS0/1/0/0 Refresh Reduction:
"Enabled" or "Disabled". Remote epoch: 0xXXXXXXXX Out of order messages: 0
Retransmitted messages: 0
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
131
Implementing RSVP for MPLS-TE and MPLS O-UNI
Verifying RSVP Configuration
