SUMMARY STEPS
1.
configure
2.
mpls traffic-eng
3.
interface type interface-path-id
4.
auto-tunnel backup
5.
attribute-set attribute-set-name
6.
Use the commit or end command.
7.
show mpls traffic-eng auto-tunnel backup summary
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters MPLS-TE configuration mode.mpls traffic-eng
Example:
RP/0/RP0/CPU0:router(config)# mpls traffic-eng
Step 2
Enables traffic engineering on a specific
interface on the originating node.
interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# interface POS 0/6/0/0
Step 3
Enables an auto-tunnel backup feature for
the specified interface.
auto-tunnel backup
Example:
RP/0/RP0/CPU0:router(config-mpls-te-if)# auto-tunnel backup
Step 4
You cannot configure the static
backup on the similar link.
Note
Configures attribute-set template for
auto-tunnel backup tunnels.
attribute-set attribute-set-name
Example:
RP/0/RP0/CPU0:router(config-mpls-te-if-auto-backup)#attribute-set
ab
Step 5
commit—Saves the configuration changes
and remains within the configuration
session.
Use the commit or end command.
Step 6
end—Prompts user to take one of these
actions:
• Yes— Saves configuration changes
and exits the configuration session.
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
228
Implementing MPLS Traffic Engineering
Establishing MPLS Backup AutoTunnels to Protect Fast Reroutable TE LSPs
