PurposeCommand or Action
Example:
RP/0/RP0/CPU0:router(config-rsvp-if)# bandwidth
mam max-reservable-bw 400 bc0 300 bc1 200
Exits the current configuration mode.exit
Example:
RP/0/RP0/CPU0:router(config-rsvp-if)# exit
Step 4
RP/0/RP0/CPU0:router(config-rsvp)#
Exits the current configuration mode.exit
Example:
RP/0/RP0/CPU0:router(config-rsvp)# exit
Step 5
RP/0/RP0/CPU0:router(config)#
Enters MPLS-TE configuration mode.mpls traffic-eng
Example:
RP/0/RP0/CPU0:router(config)# mpls traffic-eng
Step 6
RP/0/RP0/CPU0:router(config-mpls-te)#
Enables IETF DS-TE mode and default TE class map.
Configure IETF DS-TE mode on all nodes in the network.
ds-te mode ietf
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# ds-te mode
Step 7
ietf
Enables the MAM bandwidth constraint model globally.ds-te bc-model mam
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# ds-te
Step 8
bc-model mam
Exits the current configuration mode.exit
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# exit
Step 9
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
237
Implementing MPLS Traffic Engineering
Configuring an IETF DS-TE Tunnel Using MAM
