Cisco CRS Configuration Guide

DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters router MLD configuration mode.router mld
Example:
RP/0/RP0/CPU0:router(config)# router mld
Step 2
RP/0/RP0/CPU0:router(config-mld)#
Configures a virtual private network (VRF) instance.
vrf vrf-name
Example:
RP/0/RP0/CPU0:router(config-mld)#vrf default
Step 3
RP/0/RP0/CPU0:router(config-mld-default)#
Configures an MPLS-TE P2MP tunnel interface.
interface tunnel-mte tunnel-id
Example:
RP/0/RP0/CPU0:router(config-mld-default)#interface
Step 4
tunnel-mte 1
RP/0/RP0/CPU0:router(config-mld-default-if)#
Configures the multicast group address in the
Source-Specific Multicast (SSM) address range (ff35::/16)
for the IPv6 address prefix.
static-group group-address
Example:
RP/0/RP0/CPU0:router(config-mld-default-if)#
Step 5
static-group ff35::1 2000::1
commit—Saves the configuration changes and remains
within the configuration session.
Use the commit or end command.
Step 6
end—Prompts user to take one of these actions:
• Yes— Saves configuration changes and exits the
configuration session.
• No—Exits the configuration session without
committing the configuration changes.
• Cancel—Remains in the configuration session,
without committing the configuration changes.
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
310
Implementing MPLS Traffic Engineering
Configuring Point-to-Multipoint TE
