Cisco CRS

SUMMARY STEPS
1.
configure
2.
rsvp
3.
controller dwdm interface
4.
signalling refresh out-of-band interval interval
5.
signalling refresh out-of-band missed miss-count
6.
Use the commit or end command.
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters RSVP configuration mode.rsvp
Example:
RP/0/RP0/CPU0:router(config)# rsvp
Step 2
Configures a controller for establishing a GMPLS UNI tunnel.
controller dwdm interface
Example:
RP/0/RP0/CPU0:router(config-rsvp)#
Step 3
controller dwdm 0/1/0/1
Configures optical refresh interval.
signalling refresh out-of-band interval interval
Step 4
Example:
RP/0/RP0/CPU0:router(config-rsvp-cntl)#
The interval argument is the interval (in seconds) at which refresh
messages are sent and expected to be received. The range is 180 to
86400 (a refresh-interval of 1 day).
signalling refresh out-of-band interval
200
Configures number of missed refresh messages allowed before optical
tunnel states are deleted.
signalling refresh out-of-band missed
miss-count
Step 5
Example:
RP/0/RP0/CPU0:router(config-rsvp-cntl)#
The miss-count argument is the number of refresh messages, expected
at the configured refresh-interval, which can be missed before optical
tunnel states time out. The accepted range is 1 to 48. The default value
is 12.
signalling refresh out-of-band missed
30
commit—Saves the configuration changes and remains within the
configuration session.
Use the commit or end command.
Step 6
