Cisco CRS Configuration Guide

By default, NSR is globally-enabled on all LDP sessions except AToM.Note
SUMMARY STEPS
1.
configure
2.
mpls ldp
3.
nsr
4.
Use the commit or end command.
5.
(Optional) show mpls ldp [vrf vrf-name] nsr statistics
6.
(Optional) show mpls ldp vrf vrf-name nsr statistics neighbor
7.
(Optional) show mpls ldp [ vrf vrf-name] nsr summary
8.
(Optional) show mpls ldp [ vrf vrf-name] nsr pending
9.
(Optional) show mpls ldp vrf vrf-name nsr pending neighbor
10.
(Optional) show mpls ldp vrf all nsr summary
11.
(Optional) show mpls ldp nsr summary all
12.
(Optional) clear mpls ldp vrf vrf-name nsr statistics neighbor
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters the MPLS LDP configuration mode.mpls ldp
Example:
RP/0/RP0/CPU0:router(config)# mpls ldp
Step 2
Enables LDP nonstop routing.nsr
Example:
RP/0/RP0/CPU0:router(config-ldp)# nsr
Step 3
commit—Saves the configuration changes and remains
within the configuration session.
Use the commit or end command.
Step 4
end—Prompts user to take one of these actions:
• Yes— Saves configuration changes and exits the
configuration session.
• No—Exits the configuration session without
committing the configuration changes.
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
64
Implementing MPLS Label Distribution Protocol
Configuring LDP Nonstop Routing
