Cisco CRS Configuration Guide

SUMMARY STEPS
1.
configure
2.
mpls ldp
3.
mldp
4.
address-family ipv4
5.
static mp2mp ip-address
6.
end or commit
DETAILED STEPS
PurposeCommand or Action
Enters Global Configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters MPLS LDP configuration mode.mpls ldp
Example:
RP/0/RP0/CPU0:router(config)# mpls ldp
Step 2
Enables MLDP.mldp
Example:
RP/0/RP0/CPU0:router(config-ldp)# mldp
Step 3
Enables MLDP for IPv4 address family.address-family ipv4
Example:
RP/0/RP0/CPU0:router(config-ldp-mldp)#
Step 4
address-family ipv4
Enables static MP2MP LSP support and specifies MP2MP LSP root
IP address followed by the number of LSPs in the range 1 to 1000.
static mp2mp ip-address
Example:
RP/0/RP0/CPU0:router(config-ldp-mldp-af)#
Step 5
static mp2mp 10.10.10.10 1
end or commit
Step 6
•
When you issue the end command, the system prompts you to
commit changes:
Uncommitted changes found, commit them before
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
75
Implementing MPLS Label Distribution Protocol
Enabling MLDP
