Configuration with the web interface
6-36 Chapter 6: Configuration 98-150471-A02
Remote syslog
You can set up the antenna to send each syslog message to a syslog server to advise the
system administrator of the current status of the antenna.
To set up sending syslog messages to a syslog server, do as follows:
1. Select SETTINGS > Reporting.
2. In the section Remote syslog select On to enable remote syslog (default: Off).
3. Enter the IP address of the syslog server to which the syslog messages will be sent.
4. Click Apply.
SNMP traps
SNMP traps, or notifications, are network packets which advise the system administrator
about significant events in the antenna, e.g. alarms and system error messages. They are
generated by the antenna and can be sent automatically to an SNMP trap
receiver/manager. The event time is UTC time.
To set up reporting SNMP traps to an SNMP server, do as follows:
1. Select SETTINGS > Reporting.
2. In the section SNMP traps select On to enable sending of SNMP traps (default: Off).
3. Enter the IP address of the SNMP trap receiver/manager to which the SNMP traps will
be sent.
4. Enter the Community name. This is the name of the SNMP trap receiver/manager. This
is needed for authentication of the SNMP trap request.
5. Click Apply.
6.3.7 Dual antenna mode (optional)
The following tasks must be taken care of when setting up a dual-antenna system:
• To configure the Master ACU
• To configure the Slave ACU
• Blocking zone setup for dual antenna setup
• Line up and commissioning for dual antenna setup
