Configuration with the web interface
98-150471-A02 Chapter 6: Configuration 6-23
BUC TX information
The BUC TX information is displayed on the DASHBOARD in the section TX. BUC TX
indicates if the SAILOR 900 VSAT High Power VSAT has enabled the BUC or not. It can
show On or Off. This information is also shown in the display of the ACU as TX ON or TX
OFF. BUC TX On is shown when the following conditions are met:
• The SAILOR 900 VSAT High Power must sense the 10 MHz Tx reference signal from the
connected VSAT modem.
• The VSAT modem must have Rx lock.
• The antenna must point correctly to the satellite.
• The antenna must be in tracking mode.
6.3.2 Modem profiles and satellite profiles
Modem profiles
On the page Modem profiles you create, edit or delete VSAT modem profiles. The
supported modem profiles are listed in the drop-down list Modem. A modem profile
contains all modem settings that are necessary for a successful connection to the satellite.
The data you have to fill in are provided by your VSAT service and modem provider. You
must add at least one modem profile.
POINTING Description
Azimuth relative Current value for azimuth, relative to the vessel heading.
Elevation relative Current value for elevation, relative to the vessel.
Polarisation skew Current value for polarisation skew.
Table 6-10: Web interface, DASHBOARD, POINTING parameter
TX Description
BUC TX On or Off. Shows if the SAILOR 900 VSAT High Power has enabled
the BUC or not. It is the same TX ON/TX OFF as shown in the display
of the ACU, see ACU display and keypad on page 6-46.
Table 6-11: Web interface, DASHBOARD, TX parameter
SAILOR900HP.book Page 23 Monday, July 18, 2016 12:44 PM
