List of ADU events
G-2 Appendix G: System messages 98-150471-A02
G.2 List of ADU events
Error code
(ID)
Unit Severity Description Explanation
0A001-0 Antenna ERROR Production data Production data is invalid.
0A002-0 Antenna ERROR XIM internal Antenna configuration data stored in the
PCM module is invalid.
0A003-0 Antenna ERROR XIM external Antenna configuration data stored in the
VIM/TIM module is invalid.
0A004-0 Antenna ERROR XIM I/X match Antenna configuration data stored in the
PCM module does not match the
configuration data stored in the VIM/TIM
module.
0A005-0 Antenna ERROR Antenna type The configured antenna type is not
supported or unknown.
0A006-0 Antenna ERROR PCM FPGA load The PCM FPGA cannot be initialised and
loaded correctly.
0A007-0 Antenna ERROR XIM FPGA load The VIM/TIM FPGA cannot be initialised
and loaded correctly.
0A008-0 Antenna ERROR XIM production Production/calibration data stored in the
VIM/TIM module is invalid.
0A00A-0 Antenna ERROR GNSS
initialisation
The GNSS device cannot be initialised.
Check cable and GNSS device.
0A014-0 Antenna ERROR AMB device
discovery
Missing one or more of the following
devices: ISM, DDM and PMM. Check cables.
0A015-0 Antenna ERROR Azi DDM ABS
device
Cannot initialise the azimuth DDM. Info:
0x00000000: Device not found (possible
cabling problem) 0x0000bbaa: Device
internal error (replace device)
aa=status, bb=state.
0A016-0 Antenna ERROR Xel DDM ABS
device
Cannot initialise the cross-elevation DDM.
Info: See 0A015-0.
0A017-0 Antenna ERROR Ele DDM ABS
device
Cannot initialise the elevation DDM. Info:
See 0A015-0.
Table G-1: ADU event messages
