List of ADU events
98-150471-A02 Appendix G: System messages G-3
0A018-0 Antenna ERROR ISM ABS device Cannot initialise the ISM Info:
0x00000000: Device not found (possible
cabling problem)
0x000cbbaa: Device internal error (replace
device)
aa=status, bb=state, c=calibration data error.
0A019-0 Antenna ERROR PMM ABS
device
Cannot initialise the PMM. Info: See
0A015-0.
0A01A-0 Antenna ERROR BCM ABS device Cannot initialise the BCM. Info: See 0A015-
0.
0A01E-0 Antenna ERROR Sensor sanity Too many invalid values measured by the
ISM during initialisation. Check for
vibrations or malfunctioning ISM.
0A021-0 Antenna ERROR Azi axis
calibration
Azimuth axis zero reference not found.
Check belt and zero reference module. Info:
0x00000001: Timeout (operation did not
complete in time)
0x00000010: Encoder or mechanical
problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
0A022-0 Antenna ERROR Xel axis
calibration
Cross-elevation axis zero reference or end
stops not found at expected locations.
Check belt, zero reference module, and end
stops. Info: See 0A021-0.
0A023-0 Antenna ERROR Ele axis
calibration
Elevation axis zero reference or end stops
not found at expected locations. Check
belt, zero reference module, and end stops.
Info: See 0A021-0.
0A024-0 Antenna ERROR Pol axis
calibration
Polarisation axis zero reference or end
stops not found at expected locations.
Check movement of the polarisation unit
and the zero reference module. Info: See
0A021-0.
Error code
(ID)
Unit Severity Description Explanation
Table G-1: ADU event messages (Continued)
