SAILOR 900 VSAT High Power system components
98-150471-A02 Appendix A: Technical specifications A-3
Technical specifications
A.1.3 ACU
Input power Powered by ACU
Dimensions (overall) Diameter x Height: Ø 130 cm (51.3 inch) x H 150 cm
(58.9 inch)
Weight, ADU 126.5 kg (279 lbs)
Item Specification
Dimensions, rack mount
H x W x D
1U, 19 inch
4.4 x 48 x 33 cm (1.75 x 19 x 13 inch)
Weight 4.5 kg (10 lbs)
Ambient temperature Operational: -25°C to +55°C
Storage: -40°C to +85°C
Humidity IEC 60945 protected, 95% (non-condensing)
IP class IP30
Compass safe distance 10 cm (4 inch) to IEC 60945
Interfaces 1 x N-Connector for antenna RF Cable (50 Ohm)
2 x F-Connectors (75 Ohm) for Rx/Tx to VSAT modem
4 x Ethernet
1 x RS-422 data (VSAT modem control)
1 x RS-232 data (VSAT modem control)
1 x NMEA 0183 and prepared for NMEA 2000 for
Gyro/GPS compass input
1 x AC power input
1 x Grounding bolt
Input power See System power supply range and Total system
power consumption on page A-1.
Modem interface (control) iDirect openAMIP protocol & custom protocol
Comtech ROSS Open Antenna Management (ROAM)
ESS Satroaming
STM SatLink
Display OLED (red) display, 5 push buttons,
3 discrete indicator LEDs and ON/OFF switch
No transmit zones Programmable, 8 zones with azimuth and elevation
Table A-3: Technical specifications for the ACU
Item Specification
Table A-2: Technical specifications for the Above Deck Unit (Continued)
