SAILOR 900 VSAT High Power system components
A-2 Appendix A: Technical specifications 98-150471-A02
EIRP 54.3 dBW (including radome)
LNB 2 units multi-band LNBs (band selection by ACU)
Tracking Receiver Internal "all band/modulation type" DVB-S2, 300 kHz
narrowband receiver and modem RSSI
Polarisation Linear Cross or Co-Pol (selected by ACU)
Elevation Range -25° to +125°
Azimuth Range Unlimited (Rotary Joint)
Ship motion, angular Roll ±30°, Pitch ±15°, Yaw ±10°
Ship, turning rate and acceleration 15°/s and 15°/s
2
ADU motion, linear Linear accelerations ±2.5 g max any direction
Satellite acquisition Automatic - with Gyro/GPS compass input
Prepared for gyro-free operation support
Vibration, operational Sine: IEC 60945 (8.7.2), DNV No.2.4 Class A, MIL-STD-167-1
(5.1.3.3.5)
Random: Cobham Maritime Operational
Vibration, survival Sine: IEC 60945 (8.7.2) dwell, MIL-STD-167-1 (5.1.3.3.5)
dwell, IEC 60721-4-6 class 6M3
Shock MIL-STD-810F 516.5 (Proc. II). IEC 60721-4-6 class 6M3
Temperature (ambient) Operational: -25° C to 55° C
Storage: -40°C to 85°C
Humidity 100%, condensing
Rain (IP class) IEC 60945 Exposed (IPx6)
Wind resistance Operational: 80 kt.
Survival: 110 kt.
Ice Survival: 25 mm (1 inch)
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 170 cm to IEC 60945
Maintenance, scheduled None
Maintenance, unscheduled All electronic, electromechanical modules and belts can be
replaced through the service hatch.
Built-in tests Power On Self Test (POST)
Person Activated Self Test (PAST)
Continuous Monitoring (CM) with error log
Power OFF Automatic safe mode
Item Specification
Table A-2: Technical specifications for the Above Deck Unit (Continued)
