COBHAM SAILOR 900 - Appendix Edvb-S Satellites; Figure E-1: Satellite Data, Example from Www.lyngsat.com

To Next Page

To Previous Page

98-150471-A02 Appendix E: DVB-S satellites E-3

DVB-S satellites

For satellite data of other regions or transponders see www.lyngsat.com.

Example:

The above transponder has following parameters:

•Frequency: 11.038 GHz

• Polarisation: V-Vertical

• Symbol Rate: 22.000 MS/s

•NID: 1

• Coverage: Europe.

China, Japan,

Korea, Burma

Apstar 2R

(Telstar 10)

/ Apstar 7

76.5°E Vertical 11.167 GHz 45.000 MS/s 0

Osaka, Japan,

Philippines, Korea

KT 5 113°E Vertical 12.430 GHz 25.6 Ms/s 57

VSAT coverage

Satellite

name

Satellite

position

polarisation

frequency

Symbol

rate

NID

Table E-1: Examples of DVB-S satellites for azimuth calibration (Continued)

Figure E-1: Satellite data, example from www.lyngsat.com
