98-150471-A02 3-1

Chapter 3

Installation

Installation 3

This chapter is organised in the following sections:

• Unpacking

• Site preparation

• Installation of the ADU

• Installation of the ACU

• Installation of the VMU

3.1 Unpacking

3.1.1 What’s in the box

ADU

Unpack your SAILOR 900 VSAT High Power ADU and check that the following items are

present:

• ADU with 4 lifting brackets (already mounted)

• Package with bolts, washers and cable glands (2 sizes)

ACU

Unpack your SAILOR ACU VSAT KU a and check that the following items are present:

• 1 x Ethernet cable (2 m)

• 1 x Ethernet cable (short)

•Power cable (230 VAC)

• 2 x 75 Ohm coax cables F-F (1m), for Rx and Tx

• NMEA multi-connector

• Installation manual
