COMTECH 570L

98-150471-A02 Appendix C: VMU settings C-19

VMU settings

C.5 COMTECH 570L

C.5.1 Protocol and interfaces

The following sections describe how to connect the ACU to a COMTECH 570L VSAT

modem.

Protocol

The ACU supports 4800 or 9600 baud on the serial port. You can set the baud rate of the

COMTECH 570L at its front MMI.

The ACU issues the following commands on the serial interface to the COMTECH 570L

modem:

• 0000/EBN?

• 0000/TFQ?

• 0000/LLO?

• 0000/BLO?

• 0000/RFQ?

An example of the serial communication between the ACU and the COMTECH 570L

modem is shown below:

0000/EBN?

0000EBN=11.8

0000/TFQ?

0000/TFQ=1310.7956

0000/EBN?

0000/EBN=11.8

0000/LLO?

0000/LLO=10000+

0000/EBN?

0000/EBN=11.9

0000/BLO?

0000/BLO=12800-

0000/EBN?

0000/EBN=11.8

0000/RFQ?

0000/RFQ=1367.5500
