Chapter 7
Installation check 7
Now that you have installed the system, you can test it to verify it is ready for customer
delivery. Follow the check lists below to test the system for proper operation.
• Installation check list: Antenna
• Installation check list: ACU, connectors and wiring
• Installation check list: Functional test in harbor
7.1 Installation check list: Antenna
Step Task Further information Done
1.
Check that the antenna is free of
obstructions.
See Obstructions (ADU shadowing) on
page 3-4.
2.
Make sure there is sufficient
space for access through the
service hatch.
See To install the ADU on page 3-18.
3.
Make sure to maintain the
vertical orientation of the ADU
center line.
4.
Check that the ADU is installed
where vibrations are limited to a
minimum.
5.
Check that you programmed the
blocking zones correctly.
See Blocking zones – azimuth and
elevation on page 3-5
and
To set up blocking zones (RX and TX)
on page 6-28.
6.
Make sure that the safety
distance for radiation hazard is
47 metres.
See Safe access to the ADU: Radiation
hazard on page 3-6.
7.
Check that the mounting height
of the antenna is in accordance
with the ship’s min. roll period.
See Ship motion and offset from the
ship’s motion centre on page 3-7.
Table 7-1: Installation check list: Antenna
