Configuration with the web interface
6-22 Chapter 6: Configuration 98-150471-A02
• Pointing antenna (locating the satellite)
• Acquiring signal (acquiring the satellite signal)
• Tracking (tracks the current satellite)
•Lineup (line up is activated)
•Azimuth calibration
• TX cable calibration
•Test
•Not ready (waiting for input from GNSS, e.g. GPS)
•Not ready: Initializing
• Not ready: Need pos
•Blocking zone (antenna is pointing into a blocking zone)
•No TX zone (antenna is pointing into a no TX zone; TX is off)
Sections on the Dashboard
DASHBOARD Description
GPS position Current position of the vessel, reported by the GPS module
Vessel heading Ship’s heading in degrees with reference to North, provided by
the ship’s gyro.
Satellite profile Name of the currently active satellite profile.
Satellite position Position of the satellite selected in Satellite profile.
RX polarisation Horizontal or vertical.
TX polarisation
a
a. Can be changed when using a generic modem profile.
Co-pol or X-pol, auto-selected by VSAT modem
RX RF frequency
a
Ku band receiving frequency, auto-selected by VSAT modem
LNB Lo frequency
a
Auto-selected by VSAT modem
TX RF frequency
a
Auto-selected by VSAT modem
BUC Lo frequency 12.8 GHz (system parameter)
Tracking RF frequency Current RF tracking frequency.
ACU part name,
Antenna part name,
ACU serial number,
Antenna serial number,
Software version
Part names, serial numbers for ACU and ADU, software version
of the SAILOR 900 VSAT High Power.
Table 6-9: Web interface, DASHBOARD, SAILOR 900 VSAT High Power parameters
