List of ADU events
G-4 Appendix G: System messages 98-150471-A02
0A025-0 Antenna ERROR Antenna
calibration
One or more errors occurred during
antenna start-up Info:
0x00000001: Timeout (calibration did not
complete in time)
0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis
0x00000080: Polarisation axis
0A028-0 Antenna ERROR Demodulator
load
The second receiver demodulator cannot
be initialised and loaded correctly.
0A029-0 Antenna ERROR XIM PLL lock The PLL on the VIM/TIM does not lock.
0A02B-0 Antenna ERROR ABS software
version
The ABS software version in the antenna is
too old to match the hardware
requirements. Upload new software via the
web interface.
0A034-0 Antenna WARNING ACU
communication
The communication link between ACU and
antenna is not working.
0A035-0 Antenna WARNING ISM data valid Sensor measurements from the ISM are
invalid. This indicates a malfunctioning ISM.
0A036-0 Antenna WARNING ISM data range Sensor measurements from the ISM are out
of range.
0A037-0 Antenna WARNING GNSS
communication
Lost connection to the GNSS device.
0A038-0 Antenna WARNING GNSS data range Received information from the GNSS
device which is out of range.
0A039-0 Antenna WARNING GNSS device
warning
Local GNSS device warning.
0A03A-0 Antenna WARNING GNSS device
error
Local GNSS device error.
0A03B-0 Antenna ERROR Azi DDM
shutdown
The azimuth motor control has detected
one of the following situations: Extreme
temperature, voltage, current or velocity.
The motor was then shut down. This is
usually a temporary situation and is
probably fixed by a restart of the system.
0A03C-0 Antenna ERROR Xel DDM
shutdown
As Azi DDM shutdown but detected by the
cross-elevation motor control.
Error code
(ID)
Unit Severity Description Explanation
Table G-1: ADU event messages (Continued)
