SAILOR 900 VSAT High Power
Quick guide
Introduction
This quick guide aims at experienced service personnel who have installed the SAILOR 900 VSAT High
Power system and connected power. It lists the minimum configuration tasks you have to make before
the system. can be used on-air on a satellite.
Prerequisites
1. Connect a PC to the front LAN connector or the LAN3 connector at the rear of the Antenna Control
Unit.
2. Open an Internet Browser and type the default IP address of the SAILOR 900 VSAT High Power:
http://192.168.0.1 to access the web interface.
Configuration tasks (minimum)
You find a flow chart for the calibration procedure on page 6-14.
98-150471-A02
Configuration task What to do and where to find more information
Heading input
Configure the heading mode to External under SETTINGS >
Navigation. For more information see Table 6-2 on page 6-4.
Connect the ship’s heading (RS-422, NMEA0183) to the NMEA 0183 multi-
connector. Pin 8 Ship Ground/Shield (connect only one end), Pin 9 Line B +,
and Pin 10 Line A-. For more information see NMEA 0183 connector on
page 4-3.
Azimuth calibration
Make an azimuth calibration under SERVICE > Calibration to ensure that
the SAILOR VSAT can point and receive satellite signal. For more
information see Azimuth calibration on page 6-7.
TX cable calibration
Make a Tx cable calibration under SERVICE > Calibration to ensure that
Tx power is calibrated at all frequencies. For more information see Cable
calibration on page 6-11.
See Appendix E or http://www.lyngsat.com for DVB-S transponder
information.
Modem connection
Connect cables between the modem and the ACU. For more information
see VMU settings on page C-1.
Modem profile
Configure the modem profile under SETTINGS > Modem profiles. For
more information see Modem profiles on page 6-23
Network settings
Configure the network settings under SETTINGS > Network if the
modem communicates with IP to the ACU. For more information see To
configure the LAN network on page 6-30.
Satellite profile
Configure the satellite profile under SETTINGS > Satellite profiles and
then activate the satellite profile and wait for the system to acquire the
satellite and start tracking. For more information see Satellite profiles on
page 6-26 and Satellite profiles on page 6-26.
