f54716703/30/2020
B CA
NOTE: The reflective area of the headlamp has been painted white to show details of the assembly.
A. Bulb Positioned in Headlamp Housing
B. Bulb Twisted an Eighth of a Turn
C. Bulb Twisted a Quarter Turn, Tabs Against Metal Stops
Fig. 22.7, Proper Bulb Installation, Front View
f54713403/17/2020
OK OK OK
B CA
A. Bulb Positioned in Headlamp Housing
B. Bulb Twisted an Eighth of a Turn
C. Connector Pointing Straight Down
Fig. 22.8, Improper and Proper Bulb Installation, Back View
Headlights
22.5
