Marker Interrupt
NOTE: This switch may not be available in all
export markets.
The marker interrupt switch is located in the right-
hand switch pod of the steering wheel for the ICUC
system (see
Fig. 4.6), and the left-hand button pod
of the steering wheel for the ICC5 button (see
Fig. 4.7). Pressing it temporarily flashes the marker
lights.
Pretrip Light Test Switch
When the driver presses the pretrip light test switch,
shown in
Fig. 4.8, all exterior lights are activated so
the driver can exit the vehicle and verify they are
working properly. For additional information see
Chapter 25 Pre- and Post-Trip Inspections and
Maintenance.
Spotlight
The spotlight switch is located on the pivoting handle
of the spotlight. There may be a single spotlight as-
sembly mounted above the driver’s door, or one
above each door.
Turn Signals
The turn-signal lever is mounted on the left-hand
side of the steering column. Pulling the turn-signal
f61126402/17/2017
1
3
2
4
1. Headlight Control
Symbols
2. Windshield Wiper
Switch
3. Windshield Washer
Switch
4. Turn Signal Symbol
Fig. 4.5, Steering Column-Mounted Turn Signal Lever
f611352e08/14/2019
8
7
1
2
3
4
6
5
1. Cruise Accelerate/Resume
2. Quick Access System Settings
3. Cruise Decelerate/Set
4. Phone Hang-Up/Reject
5. Marker Interrupt
**
6. Phone Pick-Up
7. Headlamp Interrupt
**
8. Cancel Cruise Control
**
Not available in all markets
Fig. 4.6, Steering-Wheel-Mounted Right-Hand Switch
Pod - ICUC
f611531a10/25/2018
1
2
3
4
5
6
A
A. Menu Button—Press the button to access
instrument panel menus. When the button is
pressed, information appears on the driver display
screen.
1. Cruise Accelerate/Resume
2. Back Button
3. Quick Access System Settings
4. Marker Interrupt
5. Cancel Cruise Control
6. Cruise Decelerate/Set
Fig. 4.7, Steering-Wheel-Mounted Left-Hand Pod - ICC5
Driver Controls
4.4
