Select each check box to enable/include
that prefix. This allows the transmission of
codes belonging to the Code 128 and Code
39 families having any of the following
selected characteristics:
starting with '420' and with length 8 or
12 digits
starting with '421' and with length from 6
to 15 digits
starting with '51L' and with length 8, 9 or
12 digits
starting with '52L' and with length 8, 9 or
12 digits
starting with '54L' and with length from 6
to 19 digits
starting with '55L' and with length from 6
to 19 digits
Select the check box to enable the DPD Code Filters
panel.The DPD Code Filters panel allows selection of the
DPD code to be transmitted. All codes different from the
selected DPD will also be transmitted.
Enable
SSCC-18
Code Filter
Select the check box to enable. If selected, only the GS1-128
code, type SSCC-18, of the Code 128 family is transmitted.
All codes different from the GS1-128, type SSCC-18, will
also be transmitted.
Enable
German Post
2/5 IL Code
Filter
Select the check box to enable. If selected, only the German
Post codes of the 2/5 Interleaved code family are
transmitted. All code families different from the 2/5
Interleaved will also be transmitted.
Select the check boxes as needed to enable. If selected,
these parameters allow selecting the desired communication
channel (Main, Aux, User Socket#n) to be used for
transmitting barcode messages coming from slaves.
The selection is available only if the desired communication
channel is free (Data TX parameter disabled).
The diagnostic data format can be defined through the
commands provided by a terminal interface.
Select the check boxes as needed to enable. If selected,
these parameters allow selecting the desired communication
channel (Main, Aux, User Socket#n) to be used for
transmitting debug messages coming from slaves.
The selection is available only if the desired communication
channel is free (Data TX parameter disabled).
