E-GENIUS
69
4
Field Name
Action/Definition
Encoder
Step
(hundredths
of
millimeter)
Enter the step value of the encoder. See section 1.8.1 for a table of
Encoder Step values.
Conveyor
Speed
(mm/sec)
This parameter is available only when the Physical Encoder is
disabled. It defines the constant speed of the conveyor in mm/sec.
PackTrack
Refer to section 5.6 for physical PackTrack installation procedures.
Trigger Source
Start Input
from Bus
This parameter is available only for Fieldbus Hosts and if
checked, allows the Fieldbus Master to drive the Reading Phase.
For Profinet or Profibus interfaces, it allows the Fieldbus Master
to drive the reading phase via bit 7 in Byte 0 (LSB) of the Output
Area.
For EtherNet/IP, it allows the EtherNet/IP Client to drive the
reading phase via bit 7 in Byte OutputBits of the DL_OutputStruct.
Start Input
Number
Select an input from the drop-down list to define the number of
the input starting the reading phase.
Start Input
Active Level
Select Active Open or Active Closed from the drop-down list to
define the active state of the input.
 Active Open: The input is active when there is no current
flowing through IN pins. The input from the trigger source
is normally closed. The scanner goes into trigger mode
when the input source is opened.
 Active Closed: The input is active when current flows
through IN pins. The input from the trigger source is
normally opened. The scanner goes into trigger mode
when the input source is closed.
Transmission
Edge
Select Trailing or Leading from the drop-down list to define the
signal edge of the stop input used by the scanner as reference for
ending the reading phase:
 Trailing: The reading phase ends when the pack has
completely passed by the stop input.
 Leading: The reading phase ends as soon as the stop
input detects the front edge of the pack.
