Product Reference Guide 141
Appendix B
Cable Pinouts
Standard Cable Pinouts (Primary Interface Cables)
RS-232
Pin 1
10 Position RJ
(Scanner End)
1
2CTS
3
4RTS
5RXD
6TXD
7
8 VCC IN (5V ONLY)
9GND
10
